| Technical Data |
| Material | Contact with the product components | 304/316L(1.4306/1.4404) | Can provide material inspection report |
| Materal no contact with the product components | 304(1.4301) |
| Sealing material | Standard | silicon | Adopt sealing material with all the seal
material the FDA 117.2600 |
| Option | EPDM/FPM |
| Pressure | Pressure of work | 0-10 bar |
| Control air pressure | 5-8 bar |
| Temperature | Working temperature | Silicon:(-50~+180ºC) EPDM(-20~+135ºC) FPM(-30~+230ºC) |
| Sterilization temperature | 150ºC(Max 20min) |
| Surface treatment | Inside surface treatment | Ra≥0.4-0.8μm |
| Surface treatment | Ra≥0.8-1.6μm |
| Connection | Diameter Standard | RJT |
| Connection mode: | Male/Female Connection |
| Optional driven | Brainpower |
| Pneumatic control | Pneumatic head Gripper handle(stainless steel&plastic) Postions-G12 |
